Step 23: SMTP Email Alerts
Send automated email alerts when entity values change using the SMTP service.
Full reference
For complete details, field tables, and limitations, see the SMTP & Email Alerts reference.
SMTP Protocol Service
ControlBird's SMTP service sends automated email notifications when entity values change. Use it to alert operators about critical conditions, send daily reports, or notify teams about system events.
Email Notifications
Send emails through any SMTP server when entity values change. Supports TLS/STARTTLS encryption, authentication, and customizable templates.
OAuth Integration
When a user triggers a change, the email can be sent from their OAuth email address automatically, which helps with audit trails and personalized notifications.
How It Works
The SMTP service uses the standard mapper pattern: when an entity's Data field changes, the mapper triggers the controller to send an email.
Setting Up SMTP
SMTP configuration requires three entities: a SmtpClientController, a SmtpClientEndpoint, and one or more SmtpMapper entities.
1. Create the Controller
The controller manages the overall SMTP service. Create it under your /Root/Controllers folder:
2. Configure the Endpoint
The endpoint defines your SMTP server connection. Add it as a child of the controller:
SmtpClientEndpoint
Gmail App Passwords
If using Gmail, you'll need to create an App Password in your Google Account settings. Regular passwords won't work with SMTP when 2-factor authentication is enabled.
3. Create Mappers
Each mapper watches a specific entity and sends emails when its value changes:
SmtpMapper
Template Variables
Use these placeholders in your subject and body templates:
Example Templates
Alert: {{entity_name}} changedValue changed to {{value}} at {{timestamp}}ControlBird: {{entity_name}} Update<h2>Value Update</h2>
<p>Entity: <strong>{{entity_name}}</strong></p>
<p>New Value: <code>{{value}}</code></p>
<p><small>{{timestamp}}</small></p>OAuth Email Integration
When UseWriterEmailIfAvailable is enabled on the endpoint, the SMTP service can send emails from the OAuth user's email address instead of the default FromAddress.
How It Works
An OAuth-authenticated user modifies an entity value
The service records which user made the change
The service checks whether that user signed in through OAuth (OpenID Connect)
For an OAuth user, their email address becomes the From address
Fallback Behavior
If the author is not an OAuth user, has no OAuth email address set, or UseWriterEmailIfAvailable is disabled, the endpoint's default FromAddress is used instead.
Rate Limiting
Use the CooldownMs field to prevent email floods. When set, the mapper will skip sending emails if one was sent within the cooldown period.
Runtime Statistics
Each mapper tracks statistics that you can monitor:
Common SMTP Configurations
Gmail
Microsoft 365
Amazon SES
Troubleshooting
Emails not being sent
- Check endpoint config: Verify Host, Port, and Security match your SMTP server
- Check credentials: Username and Password must be valid
- Check FromAddress: Must be a valid email format
- Check mapper Recipients: At least one valid recipient required
- Check service logs: Look for SMTP errors in cb-smtp logs
Authentication failed
- Gmail: Use an App Password, not your regular password
- Office 365: May need to enable SMTP AUTH in admin settings
- Check username format: Some servers require full email address
Emails going to spam
- SPF/DKIM: Configure DNS records for your sending domain
- FromAddress: Use a real, verified email address
- Content: Avoid spam trigger words in subject/body
OAuth email not being used
- Check endpoint setting: UseWriterEmailIfAvailable must be true
- Check the user's sign-in method: the user must have signed in through OAuth (OpenID Connect)
- Check the user's email address: the OAuth account must have an email address on file
Walkthrough Complete!
You now have a complete ControlBird deployment with devices connected, automations running, monitoring configured, access controlled, custom scripts, professional dashboards, multi-node scaling, fault tolerance, and email notifications.
What's Next?
You've completed the full walkthrough! Here are some advanced topics to explore:
- Faceplate Builder: Create custom device control panels with graphics
- Schematic Builder: Design P&ID diagrams linked to live data
- Certificate Management: Configure TLS for secure device connections
- Config Manager: Version control your entire configuration
Keep Building
ControlBird grows with your needs. Start with what you've learned, then expand as your automation requirements evolve. Every device you connect, every automation you build, and every notification you configure makes your system more capable.
